太陽光発電所の建設において、人件費と現場での設置効率は、プロジェクトの均等化発電原価（LCOE）を直接左右する重要な要素です。従来の太陽光発電架台システムでは、設置作業員は、散乱した金具、煩雑な計測とマーキング、正確なチャンネルの位置合わせ、そしてボルトの締め付けといった作業に直面することがよくあります。これは、膨大な労働時間を消費するだけでなく、緩んだ金具が落下する危険性から、高所作業時の安全リスクも高めます。

こうした業界の課題を解決するため、SOEASYは次世代のSOEASY屋上太陽光発電架台システムを発表しました。工場での100%事前組み立てと革新的な「フックイン」式モジュール設置を組み合わせることで、現場での設置効率が30%～50%向上し、屋上太陽光発電の迅速な導入という新たな時代を切り開きます。

1. 現場での比較：従来システムとSOEASYマウントシステム

比較次元従来の太陽光発電用架台システムSOEASYマウントシステム
Shipping ConditionShipped as loose parts (bolts, spring washers, clamps, and sliders completely separated); assembled on-site.100% pre-assembled at the factory (clamp and hook kits arrive as complete modules).
Installation LogicMust slide in from the rail end or manually align with the bolt channel on-site.Hooks into the rail at any point; side-hooking enables instant self-positioning and locking.
Construction StepsTedious marking, alignment, bolt threading, and repeated adjusting and tightening.Modular quick alignment; a single worker with a single tool can complete locking efficiently.
Hardware ManagementLoose hardware easily drops and gets lost on roofs, wasting time on replacements.Zero risk of lost loose hardware; cleaner, safer high-altitude operations.

2. 主な利点1：工場での事前組み立てにより、箱から出してすぐに使える体験を実現

To minimize shipping volume, traditional mounting manufacturers often package clamps, bolts, and sliders as loose items. Installers must manually thread bolts through washers and sliders on narrow, sloped roofs, which frequently leads to hardware mismatching or dropped components.

SOEASY reimagines the delivery workflow from the source:

On automated factory assembly lines, the mid-clamp kits, end-clamp kits, L-feet kits, and SE01 roof clamps for the SOEASY system are 100% pre-assembled prior to shipment.

  • Zero On-Site Assembly: Installers open the packaging box to find ready-to-use integrated modules featuring pre-fitted bolts, washers, and innovative hook components.
  • Standardized Quality: Factory pre-assembly ensures consistent torque and clamping force across all units, eliminating structural safety risks caused by improper manual assembly on-site.

3. 主な利点2：革新的なフックインロジック ―「スライドさせるのではなく、フックで固定する！」

Traditional clamp designs rely on sliding in from the rail end or inserting vertically, requiring workers to mark lines and measure positions on the rail before carefully pushing sliders along the channel. If a module in the middle shifts slightly, the entire row of clamps must be readjusted.

The KG-C10 innovative hook structure developed for the SOEASY system offers a revolutionary “Hook-In” installation experience:

  • Hook In at Any Position Without Prior Marking:
    Workers do not need to slide components from the rail end, nor do they need to mark alignment lines. Simply take the pre-assembled clamp kit and tilt it to hook it directly into the C-channel rail at any desired location.
  • Physical Engagement for Hands-Free Locking:
    Once hooked in from the side, the clamp automatically engages with the inner lip of the rail for immediate physical positioning. Installers can free both hands to align the solar module, then tighten the bolt using a standard power tool. A single worker can execute the installation seamlessly.

4. モジュール式「ビルディングブロック」設置：EPC企業と設置業者の能力強化

Thanks to factory pre-assembly and hook-in design, the SOEASY Mounting System realizes true modular, building-block construction:

  1. Reduced Labor Dependency: High-skilled workers are no longer needed for manual line marking and complex alignment. General laborers can operate efficiently after a quick demonstration, significantly lowering labor barriers and costs.
  2. Accelerated Project Delivery: Taking a standard 1×10 array (10 modules) as an example, pre-assembled kits paired with any-point hook-in locking cut row installation time by up to 50% compared to traditional solutions, helping commercial and industrial projects grid-connect earlier.
  3. Enhanced Safety and Efficiency: Reducing worker fatigue and movements on sloped roofs minimizes high-altitude operational hazards while maintaining clean site management.

SOEASYで太陽光発電の設置を簡単に

From “tedious marking, alignment, and bolt tightening” to “factory pre-assembly and any-point hook-in locking,” the SOEASY Rooftop Solar Mounting System addresses the industry’s demand for efficiency and safety through practical engineering innovation.

Choosing SOEASY means saying goodbye to complex on-site labor and embracing standardized, modular, and rapid installation. Making every rooftop solar installation truly “SO EASY”!
